MECHANICAL

Diameter

1.62 in. (41 mm)

Length (excluding connector)

4 in. (102 mm)

Weight in air

7.7 oz. (0.22 kg)

Weight in seawater

2.8 oz. (0.08 kg)

Depth Rating

6560 ft. (2000 m)

Housing Material

Anodized Aluminum

Port Material

Acrylic

ELECTRICAL

Input Voltage

24 VDC

Power

20 Watts

CONNECTOR

Standard Connector

XSG-3-BCL

Mate for Standard Connector

RMG-3-FS

1. Power (+)

2. Ground / Common

3. 0-24 VDC Controll
